Description
Product model | 3 WPZ-1000A(G4) |
Overall dimensions (mm) | 6000×2450×2650 |
Matching power | Diesel engine; 74kw |
Medicine tank capacity | 1000L |
Ground clearance | 85cm |
Spraying width | 25m |
Matching nozzle | Fan-shaped anti-drip nozzle |
Matching liquid pump | Diaphragm pump; 100L/min |
Travel system | Hydraulic power; four-wheel drive; four-wheel steering |
Wheel width | 187cm |
Tyre type | Pneumatic rubber tire |
Spray boom control type | Hydraulic folding, hydraulic lifting |
Remarks | Simple shed as standard, fertilizer spreader as optional Configuration can be customized |
