Description
| Product model | 3 WPZ-700H |
| Overall dimensions (mm) | 4550×1650×2200 |
| Matching power | Single-bar diesel engine; 17.6kw |
| Medicine tank capacity | 700L |
| Ground clearance | 94cm |
| Spraying width | 10.3m |
| Matching nozzle | Fan-shaped anti-drip nozzle |
| Matching liquid pump | Three-steel plunger pump; 32-48L/min |
| Travel system | Hydraulic power; four-wheel drive, four-wheel steering |
| Wheel width | 155cm |
| Tyre type | Pneumatic rubber tire |
| Spray boom control type | Hydraulic folding, hydraulic lifting |
| Remarks | Simple shed as standard Configuration can be customized |
